400W – 1800W Professional Stadium Lighting ISF

✔ SYSTEM EFFICACY: up to 150lm/W
✔ DISTRIBUTION OPTIONS: 15D/20*30D/30D/35*85D/PG30D(45°x115°)/PG60D(60°x125°)
✔ LED Model: 5050/Z5M4 3535
✔ HDTV: TLCI>95, GR<30/40 (Optional)
✔ LIGHT CONTROL: Glare control, Custom visors for additional cutoff and spill light control, Support dimming, DALI, DMX512
✔ HOUSING:Heavy-duty die-cast aluminum (EN AC-46100)
✔ IP & IK RATING: IP66/IK08
✔ WARRANTY: 5 years in standard, 10 years optional

Learn More

Level Next Professional Stadium Lighting Solution-ISF Series

Elevate your lighting with Level Next professional sports lighting ISF-Series, featuring 400W LED stadium lights designed for energy-efficient and cost-effective illumination. Optimized for HD TV live streaming, this series offers a choice between a special reflector design and regular PC lens options, making it ideal for sports stadiums and large outdoor applications such as ports and docks. The high-performance design ensures exceptional energy efficiency, easy component replacement, and eco-friendly operation.

Key Features:

  • Outstanding Efficacy: Delivers up to 150 lumens per watt, providing bright, efficient lighting for various applications.
  • Special Gaming Design: Features a special reflector design or optional PC lens to minimize glare, optimize illumination and uniformity, and support 4K & HD TV live streaming (TLCI>95, GR<30/40)
  • Versatile LED Options: Compatible with Seoul 5050, CREE, LUMILEDS, and Seoul Z5M4 3535 LEDs, offering adaptable lighting solutions.
  • Enhanced Surge Protection: Optional 10kV or 20kV surge protection to safeguard against electrical surges.
  • Exceptional Vibration Resistance: 3G-rated for durability, compliant with IEC 68-2-6 standards.
  • Superior Protection Ratings: Rated IP66 for dust and water resistance and IK08 for impact resistance, meeting EN 60529 and EN 62262 standards.
  • Advanced Surface Treatment: Anti-UV thermosetting polyester or 80-micron epoxy primer with anti-UV thermosetting polyester, ideal for extremely corrosive environments.
  • Flexible Mounting Options: Available in multiple mounting types: TYPE-A (Top-fixed I), TYPE-B (Yoke Mount), TYPE-Bx (with Driver Box), and TYPE-C (Top-fixed II).
  • Long Lifespan: L90B10 rated for over 100,000 hours at 25°C.
  • Smart Lighting Control: Supports Zigbee and other wireless control options, including dimming and DMX512 settings for precise lighting management.

Recommended Uses:

  • Sports Stadiums and Pitches:
  • Ideal for illuminating sports facilities with high efficiency and reliability.
  • Train Stations & Sea Ports:
  • Perfect for large-scale outdoor operations and transportation hubs.
  • Large Outdoor Operations:
  • Suitable for extensive outdoor areas requiring bright and durable lighting.

Upgrade to the Level Next ISF-Series for high-efficiency, durable, and versatile lighting that meets the demands of professional sports venues and large outdoor spaces.

WARRANTY

5 Year Limited Warranty, 10 Year Preferred Warranty. Please consult with our sales for detailed agreement..

CERTIFICATION/LISTING

UL/cULus, CE, ROHS, ENEC standard, for detailed certificates please request
